W66 Industrial IP66 Switchgear

IPD MOTOR RATED ISOLATING SWITCH 2P 20A 250V LESS BASE, IP66 W66IS220LB

Product Code: W66IS220LB

Motor rated isolating switch 2P without base, IP66. Current rating: 20A, voltage rating: 250V. Max cable area: 16mm². Stainless steel fixings included. Padlockable for added security. Requires W66B1 base.

Technical Specifications

Brand IPD
Back Box Included No
Cover Style Light Grey
Degree of Protection IP66
Dimensions (mm) 101W x 101H x 109D
Gland Entries 2 x M25 + 1 x M32
Material Polycarbonate
Maximum Cable Cross Section (mm²) 16
No. of Poles 2
Rated Current (A) 20
Rated Voltage AC/DC (V) 250
Standards and Approvals IEC947-3/AS3133
