IPD MOTOR RATED ISOLATING SWITCH 2P 20A 250V, IP66 W66IS220
Zoom
Zoom
Zoom
IPD MOTOR RATED ISOLATING SWITCH 2P 20A 250V, IP66 W66IS220
Product Code: W66IS220
Motor rated isolating switch 2P with full size back box, IP66. Current rating at 20A, voltage rating at 250V. Max cable area 16mm² and stainless steel fixings, padlockable. Introducing the Motor Rated Isolating Switch 2P with Full Size Back Box. This switch is designed to provide a safe and reliable way to isolate motors. With an IP66 rating, it offers excellent protection against dust and water ingress. The current rating is 20A, making it suitable for a variety of motor applications. It has a voltage rating of 250V, ensuring compatibility with standard electrical systems. The switch can accommodate cables up to 16mm² in size, allowing for easy installation. Additionally, it features stainless steel fixings for added durability and is padlockable for enhanced security.
Technical Specifications
Brand
IPD
Back Box Included
Yes
Cover Style
Light Grey
Degree of Protection
IP66
Dimensions (mm)
101W x 101H x 109D
Gland Entries
2 x M25 + 1 x M32
Material
Polycarbonate
Maximum Cable Cross Section (mm²)
16
No. of Poles
2
Rated Current (A)
20
Rated Voltage AC/DC (V)
250
Standards and Approvals
IEC947-3/AS3133
