<p>The YW Series Pushbutton is a robust and reliable component designed for industrial and commercial applications where performance and durability are key. This pushbutton operates at a rated voltage of 24 VAC/DC, making it suitable for various control systems. Its illuminated design, featuring an amber built-in LED lamp, ensures visibility even in low-light environments.</p><p>Measuring 30 mm in width, 41.4 mm in height, and 64.8 mm in depth, this compact device fits seamlessly into standard configurations with a cutout size of 22 mm. The actuator type is extended, providing ease of use while maintaining functionality as a momentary switch.</p><p>Engineered to withstand harsh conditions, the pushbutton boasts an operational temperature range from -20 to 55 degrees Celsius and can be stored safely between -40 to 85 degrees Celsius. It also supports humidity levels ranging from 45% to 85%, ensuring consistent performance across diverse environments.</p><p>In terms of protection, the front panel is rated IP65 against dust and water ingress, while the terminal section holds an IP20 rating. These features make it suitable for installations where exposure to moisture or particles might be a concern.</p><p>The pushbutton&#39;s mechanical life is impressive with up to five million operations for single contact blocks and one million operations for double contact blocks. The contact configuration includes one normally open (1NO) contact made from silver material to ensure optimal conductivity.</p><p>Safety and compliance are paramount; thus, the YW Series Pushbutton comes cULus listed, CE marked, UKCA certified, and CCC certified—guaranteeing adherence to international standards.</p><p>For installation convenience and secure connections under vibration conditions (5-55 Hz) or shock resistance (10 g/ms), screw terminals are provided. With a rated insulation voltage of 600 V and insulation resistance of 100 MOhm, this pushbutton offers reliable electrical isolation during operation.</p><p>Finally, its plastic bezel material contributes not only to durability but also provides an aesthetically pleasing finish that complements any industrial setup without compromising on safety or functionality.</p>
