Product Code: HS5D-12RNM

The IDEC HS5D-12RNM is a compact, miniature interlock switch designed for safety and reliability. It features 1 Normally Open (NO) and 2 Normally Closed (NC) contacts, with an M20 gland port size for secure cable connections. The plastic head includes a detection mechanism for head detachment to ensure enhanced safety. This switch offers easy wiring options and is also available with a metal head variant. With a high B10d value of 2.0E+15, it promises long-term durability and performance in various industrial applications.

Resistance to Shock (m/s²)	1000
Resistance to Vibrations	10 to 55Hz
Brand	IDEC
Degree of Protection	IP67
Minimum Electrical Life	100000
Minimum Mechanical Life	1000000
No. of Normally-closed Contacts	2
No. of Normally-open Contacts	1
Operating Humidity	45 to 85%
Operational Temperature Range (°C)	-30 to 70
Rated Insulation Voltage (V)	300
Rated Thermal Current - Ith (A)	10
Weight (g)	80g - Plastic Head, 110g - Metal Head
