IPD ES63M80 FUSE LINK 80A 415VAC F2 CLIP-IN BS88 TYPE 80kA MOTOR RATED USE IN SC63 HOLDER, 401190

Product Code: ES63M80

ES_M_ Clip-in (F2) BS fuse links are motor start application-specific fuses. They adhere to the standard BS88-1 & 6 and IEC 60269-2. The breaking range and utilization categories for these fuses are gG -gM. Their AC breaking capacity is ASTA 20 certified at 80 kA. These fuses have a rated current of 80A and operate at a voltage of 415VAC.

Technical Specifications

Breaking Capacity AC (kA) 80
Total Length (mm) 69
Utilisation Category gG/gM
Brand IPD
Pack Quantity 10
Rated Current (A) 80
Rated Voltage AC (V) 415
