MERSEN A4BQ700 FUSE LINK 600VAC 700A CLASS L DELAY 63X97mm 200kA BOLT-IN

The A4BQ Time delay Class 'L' bolted tag fuses provide superior protection for service entrance equipment. They offer maximum protection against short circuit let-thru current for downstream circuit components. These fuses have a built-in, 4-second time-delay characteristic at 500% of the rated current. The rejection-style design prevents replacement errors. They have a voltage rating of 600VAC/500VDC and a rated current of 700A. These fuses are suitable for a wide variety of applications including mains, feeders, large motors, lighting, heating & general loads, UPS DC links, battery disconnects, and other DC applications.
