Industrial Fuse Links

IPD FUSE LINK 35A 690VAC OFF-SET TAG 73mm FIXING 80kA A3, 400303 TIS35

Product Code: TIS35

TIS offset bolted tags-2hole fixing BS fuse links (in sizes A1 to A4) are designed for general industrial applications. They comply with standard BS88-2 and IEC 60269-2. The breaking range and utilisation categories are gG, providing good peak and let-through current limitation. The breaking capacity is AC: ASTA 20 certified to 80 kA. These fuse links have a rated current of 35A and voltages of 690VAC/460VDC.

Technical Specifications

Body Diameter (mm) 23.8
Breaking Capacity AC (kA) 80
Breaking Capacity DC (kA) 40
Fuse Shape Offset slotted bolted tags
Fuse Type BS88/A3
Insulated Metal Gripping Lugs No
Utilisation Category gG
Voltage Type AC/DC
Brand IPD
Fixing Centres (mm) 73
Maximum Ambient Temperature (°C) 40
Pack Quantity 10
Rated Current (A) 35
Rated Voltage AC (V) 690
Rated Voltage DC (V) 460
Standards BS 88-2, AS 60269, IEC 269-2-1, ASTA20
Suitable Fuse Holder RS63/RSM
