IPD NS20M32 FUSE LINK 32A 415VAC 80kA F1 CLIP-IN BS88 TYPE MOTOR RATED

Product Code: NS20M32

The NS_M_ Clip-in (F1) BS fuse links are designed for motor start applications. They comply with the standard BS88-1 & 6 and IEC 60269-2. The breaking range and utilisation categories are gG -gM. The AC breaking capacity is ASTA 20 certified to 80 kA. The rated current is 32A, and the voltages are 415VAC/240VDC.

Technical Specifications

Breaking Capacity AC (kA) 80
Breaking Capacity DC (kA) 40
Fuse Construction Type F1
Total Length (mm) 59
Utilisation Category gG/gM
Brand IPD
Connection Type Clip-In
Pack Quantity 10
Rated Current (A) 32
Rated Voltage AC (V) 415
Rated Voltage DC (V) 240
Standards and Approvals IEC 60269, BS88 Part 6
Suitable Fuse Holder SC20/S32
