MERSEN FUSE LINK 30A 1000V DC gPV 10X38mm FERRULE TYPE HP10M30

Product Code: HP10M30

The HP10M photovoltaic (PV) fuse is a 10x38mm fuse designed specifically for protecting PV string wiring in industrial rooftop and utility scale photovoltaic systems operating at 1000VDC. With a minimum breaking capacity of 1.35xIn, the HP10M fuse ensures safe circuit interruption even under low fault current conditions commonly found in PV arrays. This fuse is suitable for all photovoltaic applications, including PV string/array level protection.

Technical Specifications

Brand MERSEN
Diameter (mm) 10
Interrupting Rating (kA) 50
Length (mm) 38
Maximum Fuse Rating (A) 40.5
Pack Quantity 10
Power Loss (W) 3.93
Rated Current (A) 30
Rated Voltage DC (V) 1000
Standards and Approvals IEC 60269-6 Approved (CB Tested)
Suitable Fuse Holder CUS101
Terminal Material Tin-Plated Copper
Terminal Type Ferrule
Utilization Category gPV
