IPD FUSE LINK 20A 415VAC 80kA F1 CLIP-IN BS88 TYPE NS20

Product Code: NS20

The NS Clip-in (F1) BS fuse links are engineered to safeguard general purpose applications. They fall under the utilisation categories of gG/gM and have a tested breaking capacity of up to 80 kA. These fuse links have a rated current of 20A and can handle voltages of 415VAC/240VDC.

Technical Specifications

Breaking Capacity AC (kA) 80
Breaking Capacity DC (kA) 40
Fuse Construction Type F1
Total Length (mm) 59
Utilisation Category gG
Brand IPD
Connection Type Clip-In
Diameter (mm) 13.5
Pack Quantity 10
Rated Current (A) 20
Rated Voltage AC (V) 415
Rated Voltage DC (V) 240
Standards and Approvals IEC 60269, BS88 Part 6
Suitable Fuse Holder SC20/S32
