Industrial Fuse Links

IPD FUSE LINK 16A 550VAC OFF-SET TAG 44.5mm FIXING 80kA A1, 401226 NIT16

Product Code: NIT16

The NIT offset bolted tags-2hole fixing BS fuse links, available in sizes A1 to A4, are designed for general industrial applications. They adhere to the standard BS88-2 and IEC 60269-2. These fuse links have a breaking range and utilisation category of gG, providing good peak and let-through current limitation. The breaking capacity is AC: ASTA 20 certified up to 80 kA. The rated current is 16A, with voltages of 550VAC/250VDC.

Technical Specifications

Body Diameter (mm) 14.1
Breaking Capacity AC (kA) 80
Breaking Capacity DC (kA) 40
Fuse Shape Offset slotted bolted tags
Fuse Type BS88/A1
Insulated Metal Gripping Lugs No
Utilisation Category gG
Voltage Type AC/DC
Brand IPD
Fixing Centres (mm) 44.5
Maximum Ambient Temperature (°C) 40
Pack Quantity 10
Rated Current (A) 16
Rated Voltage AC (V) 550
Rated Voltage DC (V) 250
Standards BS 88-2, AS 60269, IEC 269-2-1, ASTA20
Suitable Fuse Holder RS20 & RSM32
