IPD FUSE LINK 160A 690VAC OFF-SET TAG MOTOR RATED 94mm FIXING 80kA A4, 400275 TCP100M160

Product Code: TCP100M160

The TCP offset bolted tags-2hole fixing BS fuse links (available in sizes A1 to A4) are designed for general industrial applications. They comply with the standard BS88-2 and IEC 60269-2. These fuse links have a breaking range and utilisation categories of gM, providing good peak and let-through current limitation. The breaking capacity is AC: ASTA 20 certified up to 80 kA. The rated current and voltages are 160A, 690VAC/350VDC.

Technical Specifications

Body Diameter (mm) 34.9
Breaking Capacity AC (kA) 80
Breaking Capacity DC (kA) 40
Fuse Shape Offset slotted bolted tags
Fuse Type BS88/A4
Insulated Metal Gripping Lugs No
Utilisation Category gM
Voltage Type AC/DC
Brand IPD
Fixing Centres (mm) 94
Maximum Ambient Temperature (°C) 40
Pack Quantity 5
Rated Current (A) 160
Rated Voltage AC (V) 690
Rated Voltage DC (V) 350
Standards BS 88-2, AS 60269, IEC 269-2-1, ASTA20
Suitable Fuse Holder RS100/CM100/RSM
