MERSEN AJT100 FUSE LINK 100A 600VAC 500VDC CLASS J DELAY 21X57mm FERRULE

Product Code: AJT100

AJT Time delay Class 'J' ferrule type fuses are designed to handle typical motor and transformer inrush currents. They have time-delay characteristics and provide superior current-limiting ability. These fuses have a voltage rating of 600VAC/500VDC and a rated current of 100A.

Technical Specifications

Body Style Bolted Tag
Fuse Class Class J
Interrupting Rating AC (kA) 200
Interrupting Rating DC (kA) 100
Brand MERSEN
Body Size (mm) 29 x 67
Functionality Time Delay
Rated Current (A) 100
Rated Voltage AC (V) 600
Rated Voltage DC (V) 500
