IPD SC20HWH FUSE FITTING 20A SAFECLIP FRONT WIRE, WHITE USE SC20/32LINK FOR NEUTRAL

Product Code: SC20HWH

The SC_HWH front connected clip-in LV fuse fittings (white) are IP20 finger-safe fuse holders specifically designed for utility and industrial installations. These fuse fittings have self-cleaning and self-aligning base contacts, ensuring optimal performance. They can be easily mounted on a DIN rail using the removable carrier. The SC_HWH fuse fittings comply with the standards BS88-1 & 6, AS60269, and IEC269-2-1. With a rated current of 20A, they provide reliable protection for your electrical system.

Technical Specifications

Breaking Capacity AC (kA) 80
Brand IPD
Body Size (mm) 75.5H x 26.5W x 54D
Carton Quantity 10
Colour White
Connection Type Front Wire
Degree of Protection IP20
Mounting Type DIN Rail
Rated Current (A) 20
Rated Voltage AC (V) 415
Suitable Type of Neutral Link SC20/32LINK
