NOVARIS DIN MOUNT SINGLE PHASE SURGE FILTER, 32A MAX SFD1-20-100-275

Product Code: SFD1-20-100-275

The Novaris SFD1-20-100-275 is a single-phase surge filter designed for protecting sensitive loads in space-restricted applications. It features a compact design, all-mode line protection, and a safe metal enclosure. With standards compliance including IEC, AS/NZS, UL, and IEEE, this product ensures robust surge suppression and noise filtering.

Technical Specifications

Maximum Load Current - I? (A) 20
Brand NOVARIS
Degree of Protection IP20
Dimensions (mm) 72W x 69H x 95L
Lightning Impulse Current (10/350 µs) - Iimp (kA) 12.5 (L-N), 15 (N-PE)
Maximum Continuous Operating Voltage MCOV AC (V) 275 (L-N), 255 (N-PE)
Maximum Discharge Current (8/20µs) - Imax (kA) 100 (L-N), 60 (N-PE)
Mounting Type DIN rail
No. of Phases 1
No. of Poles 1P+N+PE
Nominal Discharge Current (8/20µs) - In (kA) 40 (L-N), 50 (N-PE)
Nominal Voltage AC (V) 230
Operational Temperature Range (°C) -40 to 70
Series SFD1
Standards and Approvals IEC 61643-11, AS/NZS 1768, UL 1449, IEEE 62.41.2
Voltage Protection Level - Up (kV) < 2 (L-N), <1.5 (N-PE)
Weight (g) 670
