ABB PS2-2-0-125 BUSBAR PS2-2-0-125

Product Code: PS2-2-0-125

PS2-2-0-125 3-phase busbars ensure a quick and safe connection of 2 MS165 manual motor starters without lateral auxiliary contacts and are therefore a cost effective solution. The rated current is 125 A.

Technical Specifications

Module Width (mm) 18
No. of Mountable Devices 2
Rated Operational Current (A) 125
Brand ABB
Colour Grey
Connection Type Pin
Degree of Protection IP20
Length (mm) 115
Maximum Operational Voltage AC (V) 690
No. of Phases 3
No. of Poles 6
Rated Conditional Short-Circuit Current - Inc (kA) 100
Rated Impulse Withstand Voltage (kV) 8
Rated Operational Voltage AC (V) 690
Rated Short-Time Withstand Current - Icw (kA) 100
Rated Uninterrupted Current - Iu (A) 125
Suitable For 2 Devices
Width in Number of Modular Spacings 6.57
