W66 Industrial IP66 Switchgear

IPD 30MA RCD TYPE A PROTECTED SWITCHED OUTLET KIT 1 PHASE 3 PINS 20A 240V, IP66 W66SS320RCA

Product Code: W66SS320RCA

This single phase RCD Type A protected switched outlet kit features 3 pins and an IP66 rating. It has a 4M base and a current rating of 20A, with a voltage rating of 240V.

Technical Specifications

Brand IPD
Back Box Included Yes
Cover Style Silicone Gasket
Degree of Protection IP66
Gland Entries 2 x M32, 2 x M25
Material Polycarbonate
Maximum Cable Cross Section (mm²) 6
No. of Phases 1
No. of Pins 3
Pin Type Round
Rated Current (A) 20
Rated Residual Current (mA) 30
Rated Voltage AC/DC (V) 240
Standards and Approvals IP66
Type of Residual Current Type A
