Product Code: MPP-RJ12-2

The RJ Modular Plug Protector is designed to provide protection for telephone and signal lines. It can accommodate 2 pairs of connections. With a maximum continuous voltage (Uc) of 200 VDC, it ensures reliable performance. The protector has a maximum discharge current (Imax) of 10kA at 8/20 us, offering effective protection against surges. The maximum load current (IL) is 350 mA. It has a voltage protection level (Up) of <150V at 5kV (10/700us), further safeguarding your equipment. The connection type is series transverse and common mode protection stages, making it suitable for various applications.

No. of Pairs	2
Voltage Protection at 5kV (10/700µs) - Up (kV)	<0.15
Brand	NOVARIS
Connection Type	RJ12 socket
Degree of Protection	IP20
Dimensions (mm)	26H x 26W x 90D
Maximum Continuous Operating Voltage MCOV DC (V)	200
Maximum Discharge Current (8/20µs) - Imax (kA)	10
Operational Temperature Range (°C)	-40 to 85
Series	MPP
Standards and Approvals	AS/NZS 4117, AS/ACIF S002, AS/NZS 60950, AS/NZS 1768, IEC 61643-21
Weight (kg)	0.1

Lightning & Surge Protection

NOVARIS RJ MODULAR PLUG PROTECTOR 2 PAIRS 10KA MPP-RJ12-2

Product Code: MPP-RJ12-2

Technical Specifications
