Product Code: IC694MDL930

Emerson's RX3i DC Voltage Output module is a versatile component of the RX3i series, designed for automation systems. This chassis-based PLC module offers flexibility with 5 to 32 points that can be configured as group or isolated outputs. It supports both positive and negative logic, catering to high-density applications or relay controls. With robust network interfaces including PROFINET, PROFIBUS DP, Modbus TCP, EGD, and CMX, it ensures seamless integration into existing networks via dual RJ45 and SFP ports. Ideal for complex machinery, process control, motion control, and general automation tasks, this module can be mounted on a panel or DIN rail for convenient installation.

Maximum Nominal Output Voltage DC (V)	125
Maximum Temperature (°C)	60
Media Support	2x RJ45 + 2x SFP
Minimum Nominal Output Voltage DC (V)	0
Minimum Temperature (°C)	0
No. of Digital Outputs	8
No. of Ethernet Ports	2
No. of IO	8
Nominal Output Current (A)	2
Brand	Emerson
Communication Protocols	MODBUS, PROFINET, PROFIBUS
Degree of Protection	IP20
Mounting Type	On Panel / DIN Rail
Series	RX3i
Standards and Approvals	ATEX/IECeX

Programmable Logic Controllers & I/O

EMERSON RX3I AC/DC VOLTAGE OUTPUT MODULE, 4A, 8 POINT IC694MDL930

Product Code: IC694MDL930

Technical Specifications
