Product Code: IC694MDL241

The Emerson RX3i AC Voltage Input module is a versatile component of the RX3i series, designed for robust automation systems. This chassis-based module offers flexible configurations with 8 to 32 points, available in group or isolated setups. It supports both positive and negative logic, as well as high-density applications. Engineered for seamless integration into complex machinery, process control systems, motion control setups, and general automation tasks, it boasts an array of network interfaces including PROFINET, PROFIBUS DP, Modbus/TCP, EGD, and CMX. Suitable for mounting on panel or DIN rail installations, this PLC module is a reliable solution for sophisticated automation requirements.

Current Consumption	80mA @ 5V DC & 125mA @24V DC
Maximum Temperature (°C)	60
Minimum Temperature (°C)	0
No. of Digital Inputs	16
No. of IO	16
Rated Maximum Operational Voltage AC (V)	30
Rated Maximum Operational Voltage DC (V)	30
Rated Minimum Operational Voltage AC (V)	0
Rated Minimum Operational Voltage DC (V)	0
Brand	Emerson
Communication Protocols	MODBUS, PROFINET, PROFIBUS
Degree of Protection	IP20
Mounting Type	On Panel / DIN Rail
No. of Input Points	16
Rated Supply Voltage AC/DC (V)	24V AC/DC
Series	RX3i
Standards and Approvals	UL 508, equivalent to CSA C22.2 No 142M1987 standard

Programmable Logic Controllers & I/O

EMERSON RX3I AC/DC VOLTAGE INPUT MODULE, 24V, 16 POINT IC694MDL241

Product Code: IC694MDL241

Technical Specifications
