EMERSON RSTI-EP POWER MODULE, RSTI-EP 1 CHANNEL 24VDC INPUT FLOW 10A EP-7641

Product Code: EP-7641

Emerson's RSTi-EP Power Modules offer a compact solution for automation systems, specifically designed for PLC applications within the RSTi-EP series. These modules feature a single point channel density and are capable of handling 24VDC input or output with a robust flow of 10A. Engineered for versatility, they support multiple network interfaces including PROFINET, PROFIBUS DP, Modbus/TCP, and EtherCAT. The DIN rail-mounted design ensures easy installation and integration into various industrial environments.

Technical Specifications

Current Consumption 10mA, 20.4-28.8V
Maximum Temperature (°C) 60
Minimum Temperature (°C) -20
Network PROFINET PROFIBUS DP Modbus/TCP EtherCAT
No. of IO 1
Rated Maximum Operational Voltage DC (V) 24
Redundancy PNSR
Brand Emerson
Communication Protocols MODBUS, PROFINET, PROFIBUS, EtherCAT, EtherNet/IP
Degree of Protection IP20
Series RSTi-EP
Standards and Approvals ATEX/IECeX
