RED LION PoE INJECTOR 24V EB-PSE-24V-1A

Product Code: EB-PSE-24V-1A

Explore the Red Lion NT24K Series, a robust 12-Port Gigabit Managed POE+ Industrial Ethernet Switch designed to cater to demanding network requirements. This switch features eight RJ-45 ports supporting 10/100/1000BaseT and four SC duplex fiber ports for 1000BaseFX connections, ensuring high-speed data transmission over singlemode fiber with a reach of up to 40km. Engineered for reliability in industrial environments, it operates efficiently with a power input range of 22-49 VDC and a maximum input current of 11.37 A at 24 VDC. Ideal for engineers looking for durable network solutions that can handle long-distance communication without compromising on performance.

Technical Specifications

DIN Rail Width (mm) 35
Maximum Temperature (°C) 80
Minimum Temperature (°C) -40
Port Quantity and Type 1 x 10/100BASE-TX RJ45 (Data In), 1 x 10/100BASE-TX RJ45 PoE (Data & Power Out)
Rated Maximum Operational Voltage DC (V) 49
Rated Minimum Operational Voltage DC (V) 22
Brand RED LION
Degree of Protection IP20
Dimensions (mm) 100H x 25.4W x 82.8D
Mounting Type DIN Rail
Operational Temperature Range (°C) -40 to +75
Rated Voltage DC (V) 24
Series NT24K
Standards and Approvals ATEX/IECeX
