IPD CTME3600 CTME-3 SOLID-CORE CURRENT TRANSFORMER 600/5 RATIO, CLASS 0.5 10VA

The CTME-3 solid-core current transformer is a reliable and accurate device designed for measuring electrical currents. It has a current ratio of 600/5 and an accuracy class of 0.5 at 10VA. The transformer features a single turn primary winding and is built with high impact flame retardant materials, ensuring durability. For added convenience, the CTME-3 comes with a clear sealable terminal cover as standard, providing protection and security. It also includes knockouts in the terminal shrouds for easy installation. With an operating temperature range of -20°C to +70°C and insulation class B (80°C), this transformer can withstand various environmental conditions. In terms of dimensions, the CTME-3 measures 115Hx97Wx42Dmm and has a cable diameter opening of 48mm. It offers flexible mounting options, including fixed screw mounting or DIN rail mounting. The package includes mounting brackets and a busbar fixing device for easy installation. Overall, the CTME-3 solid-core current transformer is a reliable and versatile solution for accurately measuring electrical currents in various applications.
