Earth Fault Protection	DIN rail (top hat rail)
Limiting Frequency (Hz)	100
Limiting Frequency (MHz)	100
Maximum Continuous Voltage AC (V)	4.2
Maximum Continuous Voltage DC (V)	6
Mounting Method	On basic element
Nominal Voltage (V)	5
Nominal Voltage DC (V)	5
SPD Type	1
Voltage Protection Level - Up (V)	line-line for Iimp D1 (UP) ≤ 25 V line-PG for Iimp D1 (UP) ≤ 550 V line-line at 1 kV/µs C3 (UP) ≤ 11 V line-PG at 1 kV/µs C3 (UP) ≤ 550 V
Voltage Protection Level Earth	550
Brand	DEHN
Colour	Yellow
Degree of Protection	IP20
Dimensions (mm)	12W x 45H x 51D
Enclosure Material	Polyamide PA 6.6
Lightning Impulse Current (10/350 µs) - Iimp (kA)	10
Maximum Continuous Operating Voltage MCOV AC (V)	4.2
Maximum Continuous Operating Voltage MCOV DC (V)	6
Mounting Type	On Basic Element
Nominal Discharge Current (8/20µs) - In (kA)	20
Nominal Load Current AC - I? (A)	1
Operational Temperature Range (°C)	-40 to 80
Reference No.	920371
Standards and Approvals	IEC 61643-21 / EN 61643-21
Suitable For	Pluggable DIN Rail Mounted
Voltage Protection Level - Up (kV)	11
Weight (kg)	0.024

Lightning & Surge Protection

DEHN BLITZDUCTOR XT COMBINED LIGHTNING CURRENT AND SURGE ARRESTER MOD BXTML4BDHF5
