Maximum Continuous Voltage AC (V)	127
Maximum Continuous Voltage DC (V)	180
Nominal Voltage (V)	180
Nominal Voltage DC (V)	180
SPD Type	1
Voltage Protection Level - Up (V)	line-line for Iimp D1 (UP) ≤ 600 V level line-PG for Iimp D1 (UP) ≤ 550 V line-line at 1 kV/µs C3 (UP) ≤ 650 V line-PG at 1 kV/µs C3 (UP) ≤ 550 V
Voltage Protection Level Earth	550
Brand	DEHN
Colour	Yellow
Degree of Protection	IP20
Dimensions (mm)	12W x 45H x 51D
Enclosure Material	Polyamide PA 6.6
Lightning Impulse Current (10/350 µs) - Iimp (kA)	10
Maximum Continuous Operating Voltage MCOV AC (V)	127
Maximum Continuous Operating Voltage MCOV DC (V)	180
Nominal Discharge Current (8/20µs) - In (kA)	20
Nominal Load Current AC - I? (A)	1.2
Operational Temperature Range (°C)	-40 to 80
Reference No.	920310
Standards and Approvals	IEC 61643-21 / EN 61643-21
Suitable For	Pluggable DIN Rail Mounted
Voltage Protection Level - Up (kV)	600
Weight (kg)	0.025

Lightning & Surge Protection

DEHN BLITZDUCTOR XT LIGHTNING CURRENT ARRESTER MODULE BXTML4B180
