Earth Fault Protection	Other
Limiting Frequency (Hz)	6
Limiting Frequency (MHz)	6
Maximum Continuous Voltage AC (V)	23.3
Maximum Continuous Voltage DC (V)	33
Mounting Method	On basic element
Nominal Voltage (V)	24
Nominal Voltage DC (V)	24
SPD Type	2
Voltage Protection Level - Up (V)	line-line for Iimp D1 (UP) ≤ 50 V line-PG for Iimp D1 (UP) ≤ 1300 V line-line for In C2 (UP) ≤ 52 V level line-PG for In C2 (UP) ≤ 1400 V
Voltage Protection Level Earth	1100
Brand	DEHN
Colour	Blue
Degree of Protection	IP20
Dimensions (mm)	12W x 45H x 51D
Enclosure Material	Polyamide PA 6.6
Lightning Impulse Current (10/350 µs) - Iimp (kA)	4
Maximum Continuous Operating Voltage MCOV AC (V)	23.3
Maximum Continuous Operating Voltage MCOV DC (V)	33
Mounting Type	On Basic Element
Nominal Discharge Current (8/20µs) - In (kA)	10
Nominal Load Current AC - I? (A)	0.5
Operational Temperature Range (°C)	-40 to 80
Reference No.	920280
Standards and Approvals	IEC 61643-21 / EN 61643-21
Suitable For	Pluggable DIN Rail Mounted
Voltage Protection Level - Up (kV)	45
Weight (kg)	0.022

Lightning & Surge Protection

DEHN BLITZDUCTOR XT COMBINED LIGHTNING AND SURGE ARRESTER MOD BXTML2BDSEX24
