HIRSCHMANN TOFINOXE FIREWALL & SECURITY ROUTER 942 103-999-001

Product Code: 942 103-999-001

The Hirschmann TOFINOXE is a robust security device designed to enhance network solutions. It features two Ethernet ports, each capable of 10/100 Mbit/s speeds, with standard twisted pair RJ45 connections for reliable data transmission. Engineered to operate within a wide temperature range from 0°C to +60°C, this device ensures consistent performance in various environments. It supports both DC power inputs ranging from 12 to 48 V and AC power at 12 V, providing flexible installation options. Compliance with industry standards such as CE, FCC, EN 61131, and EN 60950 certifies its safety and reliability. Ideal for engineers looking for a dependable security appliance without the need for preloaded software modules, the TOFINOXE series stands out in its category.

Technical Specifications

Maximum Temperature (°C) 60
Minimum Temperature (°C) 0
Nominal Power (W) 5
Rated Maximum Operational Voltage AC (V) 12
Rated Maximum Operational Voltage DC (V) 48
Rated Minimum Operational Voltage DC (V) 12
Software Modules FW+NC+MB (Preload)
Brand HIRSCHMANN
Configuration Tofino Standard Configuration
Degree of Protection IP20
Mounting Type DIN Rail
No. of Ports 2xFast Ethernet Ports (10/100 Mbit/s), 2xTwisted Pair RJ45
Operational Temperature Range (°C) +0 to +60
Rated Operational Voltage AC (V) 12
Rated Operational Voltage DC (V) 12 - 48
Series TOFINOXE
Standards and Approvals CE, FCC, EN 61131, EN 60950
