STAHL 8161/8-M20-1307 CABLE GLAND WITHOUT REDUCTION SEALING INSERT 239180

Product Code: 239180

The Stahl Series 8161/8 cable gland is engineered for hazardous area cabling with a robust design that ensures secure and reliable cable management. This M20 thread size gland with a 1.5 thread pitch accommodates a clamping range of 7.00 to 13.00 mm, making it versatile for various cable diameters ranging from 1 to 48 mm. Constructed from polyamide and glass fibre reinforced material, it offers durability and resilience in extreme temperatures ranging from -40°C to +75°C while maintaining an IP66 rating for dust and water ingress protection. Ideal for engineers seeking high-quality cabling solutions in challenging environments.

Technical Specifications

Maximum Temperature (°C) 75
Minimum Temperature (°C) -40
Brand STAHL
Ambient Temperature Range (°C) -40 to +75
Application Application range (zones) - 1, 2, 21, 22
Certifications IECEx, ATEX, UL
Colour Blue
Degree of Protection IP66
Enclosure Material Polyamide
Material Polyamide
Mounting Type Threaded
Series 8161/8
Standards and Approvals ATEX/IECeX
Thread Size M20
