STAHL 8082/1-1-00 CONTACT ELEMENT 132636

Product Code: 132636

Explore the Stahl Series 8082 contact element, designed for hazardous area applications. This robust Ex E component features a 1 NC positive opening contact and can handle voltages from 24 to 550 VAC with a high current capacity of up to 10,000 A. Engineered to operate in extreme temperatures ranging from -60°C to +100°C and rated IP20 for protection, this contact element ensures reliable performance in demanding environments.

Technical Specifications

Maximum Temperature (°C) 100
Minimum Temperature (°C) -60
Rated Operational Current (A) 0.15/10
Switching Capacity AC-12 250V/10A, 400V/7.5A, 550V/5A
Switching Capacity AC-15 110V/10A, 250V/6A, 400V/4A
Switching Capacity DC-13 60V/6A
Switching Capacity DC-132 230V/1A, 110V/2.5A
Brand STAHL
Ambient Temperature Range (°C) -60 to +70
Application Application range (zones) - 1, 2
Cable Cross Section (mm²) 0.75 - 2.5
Certifications IECEx, ATEX, UL
Connection Type Screw Terminal
Contact Material Silver-Nickel
Contacts 1NC
Degree of Protection IP20
Enclosure Material Polyamide
No. of Poles 1
Operational Temperature Range (°C) -60 to +100
Rated Operational Voltage (V) 24 - 550
Series 8082
Standards and Approvals ATEX/IECeX
Tightening Torque (Nm) 1.2
