RED LION ETHERNET SWITCH 5 PORT UNMANAGED 105FXE-ST-15

Product Code: 105FXE-ST-15

Enhance your network's performance with the Red Lion SFP Transceiver, featuring a robust copper RJ45 interface capable of delivering speeds up to 100Mbps. Ideal for integration into any network solution that requires reliable switches, this transceiver is part of the trusted SFP series designed to meet the rigorous demands of modern networking environments.

Technical Specifications

Current Consumption (mA) 270 at 24VDC
DIN Rail Width (mm) 35
No. of 100Mb Ports 1
No. of Ethernet Ports 4
Port Quantity and Type 4 x 10/100BASE-TX RJ45, 1 x 100BASE-FX
Brand RED LION
Cable Type FX Cable - Single Mode (Max. 15km)
Connector Type FX Port - ST
Dimensions (mm) 89H x 38W x 90D
Mounting Type DIN Rail
Operational Temperature Range (°C) -40 to +70
Rated Operational Voltage DC (V) 10 - 30
Series SFP
Standards and Approvals FCC, EN61000-6-2, EN61000-6-2, EN61000-3-2, IEC61000-4-2, IEEE1613
Switch Type Switch - Unmanaged
