RED LION UNMANAGED ETHERNET SWITCH, 5 PORT 105FX-ST

Product Code: 105FX-ST

Enhance your network's reach with the Red Lion SFP Transceiver, a robust singlemode module designed for long-distance data communication up to 30km at 100Mbps. Ideal for integration into network solutions, this transceiver is part of the reliable SFP series and ensures seamless connectivity for switches requiring high-performance and durability in demanding environments.

Technical Specifications

Current Consumption (mA) 270 at 24VDC
DIN Rail Width (mm) 35
No. of 100Mb Ports 1
No. of Ethernet Ports 4
Brand RED LION
Cable Type FX Cable - Multi Mode
Connector Type FX Port - ST
Dimensions (mm) 89H x 38W x 90D
Mounting Type DIN Rail
No. of Ports 4 x 10/100BASE-TX, 1 x 100BASE-FX
Operational Temperature Range (°C) -40 to +70
Rated Operational Voltage DC (V) 10 - 30
Series SFP
Standards and Approvals FCC, EN61000-6-2, EN61000-3-2, IEC61000-4-2, IEEE1613
Switch Type Switch - Unmanaged
