Schmersal 101215518 Magnetic Safety Sensor 1m Cable

Product Code: 101215518

  • Operates at 100 VAC, 0.25 A
  • Durable with 25 million cycles
  • Stainless steel housing, IP69 rated
  • Compact size: 14.5x88x27 mm
  • Wide temp range: -25 to 80°C
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Safety Sensor
Brand SCHMERSAL
Series BNS40S
Actuating Element Magnet
Cable Length 1 m
Degree of Protection IP69
Housing Material Stainless Steel
Mechanical Life 25000000 Cycles
Mounting Type Not Flush
Operational Temperature -25 to 80 deg C
Rated Current 0.25 A
Rated Frequency 5 Hz
Rated Power 3 W
Rated Voltage 100 VAC
Sensor Size 14.5 mm L x 88 mm W x 27 mm H
Standards and Approvals BG-GS-ET-14 EN IEC 60947-5-3
Terminal Type Screw terminals
Vibration Resistance 10-55 Hz
Wire Size 0.25 sq-mm

Description

<p>In the realm of industrial and commercial applications, precision and durability are paramount. This product stands as a testament to those principles, offering reliable performance tailored for demanding environments. With a rated voltage of 100 VAC and a current capacity of 0.25 A, it delivers a power output of 3 W, ensuring efficient operation across various applications.</p><p>Designed with longevity in mind, this device boasts an impressive mechanical life of 25 million cycles. Such durability is complemented by its robust stainless steel housing, providing resilience against harsh conditions while maintaining aesthetic integrity. Its IP69 degree of protection further underscores its capability to withstand dust ingress and high-pressure water jets, making it ideal for rigorous industrial settings.</p><p>The operational temperature range from -25 to 80 degrees Celsius ensures functionality across diverse climates, while compliance with BG-GS-ET-14 and EN IEC 60947-5-3 standards guarantees adherence to safety regulations.</p><p>Installation flexibility is afforded by its non-flush mounting type and manageable cable length of 1 meter. The compact sensor dimensions (14.5 mm L x 88 mm W x 27 mm H) allow for easy integration into existing systems without compromising space or design constraints.</p><p>For those concerned with vibration impacts, the product&amp;#39;s resistance between frequencies of 10-55 Hz offers additional assurance against operational disruptions in dynamic environments.</p><p>Overall, this product represents a harmonious blend of technical prowess and practical design considerations—making it an astute choice for professionals seeking reliability coupled with advanced engineering specifications in their operations.</p>
