Schmersal 101199606 Magnetic Safety Sensor 5m Cable

Product Code: 101199606

  • Rated power of 10 W
  • Durable with 25M cycles mechanical life
  • Quasi-flush mounting type
  • IP67 protection for harsh environments
  • Operates in -25 to 70°C range
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Magnetic Safety Sensor
Brand SCHMERSAL
Actuating Element Magnet
Cable Length 5 m
Degree of Protection IP67
Housing Material Glass Fibre Reinforced Thermoplastic
Installation Conditions Quasi-flush
Mechanical Life 25000000 Cycles
Mounting Type Quasi-Flush
Operational Temperature -25 to 70 deg C
Rated Current 0.4 A
Rated Frequency 5 Hz
Rated Power 10 W
Sensor Size 13 mm L x 88 mm W x 25 mm H
Standards and Approvals BG-GS-ET-14 EN IEC 60947-5-3
Vibration Resistance 10-55 Hz
Wire Size 0.25 sq-mm

Description

<p>When evaluating industrial and commercial products, it&amp;#39;s essential to focus on the technical specifications that ensure reliability and efficiency. This product offers a comprehensive set of features tailored for demanding environments, making it a suitable choice for professionals in Australia.</p><p>With a rated current of 0.4 A and rated power of 10 W, this product is designed to efficiently handle moderate electrical loads. Its rated frequency stands at 5 Hz, which may be relevant depending on your specific application requirements.</p><p>Durability is another critical aspect, evidenced by its impressive mechanical life of 25 million cycles. This ensures long-term performance and reduces the need for frequent replacements or maintenance. The quasi-flush mounting type adds versatility to its installation options, allowing it to fit seamlessly into various setups.</p><p>The cable length extends up to 5 meters, providing ample flexibility during installation without compromising connectivity. Constructed from glass fibre reinforced thermoplastic, the housing material enhances durability while maintaining lightweight properties—ideal for tough industrial settings.</p><p>In terms of protection against environmental factors, this product boasts an IP67 degree of protection. It can withstand dust ingress and temporary immersion in water—a valuable feature when operating in challenging conditions.</p><p>Operational temperature ranges from -25&amp;#176;C to 70&amp;#176;C, ensuring functionality across diverse climates typical in many Australian regions. Compliance with standards such as BG-GS-ET-14 and EN IEC 60947-5-3 highlights its adherence to safety and quality benchmarks crucial for industry applications.</p><p>The actuating element is magnet-based, offering reliable operation with minimal wear over time. With dimensions measuring 13 mm L x 88 mm W x 25 mm H, this sensor maintains a compact profile suitable for space-constrained environments.</p><p>Vibration resistance between 10-55 Hz further underscores its robustness in dynamic settings where motion or vibration might otherwise affect performance adversely.</p><p>Wire size measures at 0.25 sq-mm—adequate for maintaining signal integrity while supporting efficient electrical flow throughout the system&amp;#39;s lifespan.</p><p>Overall, these specifications make this product an excellent candidate if you&amp;#39;re seeking something durable yet versatile enough to meet varied operational demands within industrial contexts across Australia.</p>
