Product Code: 101190042

Enhance your machine safety with the Schmersal BNS36 series safety sensor. This robust thermoplastic device is designed to ensure secure operations with its magnetic actuating element and right-hinged door configuration. It features two openers, a single shutter, and dual safety contacts, all connected through a six-wire cable system. The sensor comes equipped with a 1-meter cable for easy installation and offers reliable performance with a switching voltage of 75 VDC, current of 0.4 A, and capacity of 10 W. Ideal for engineers seeking dependable safety solutions in their machinery setups.

Brand	SCHMERSAL
eCl@ss Number, Version 11.0	27-27-27-04
eCl@ss Number, Version 9.0	27-27-26-92
ETIM 6.0	EC002549
ETIM 7.0	EC000030
Gross Weight (g)	111.65
Maximum Actuating Speed (m/s)	2
Maximum Fuse Rating	6 A gG D-fuse
Maximum Temperature (°C)	70
Minimum Ambient Temperature (°C)	-30
Minimum Temperature (°C)	-25
Net Weight (g)	148.06
Nominal Output Current (A)	0.4
Nominal Power (W)	10
Rated Maximum Operational Voltage DC (V)	75
Sensor Height (mm)	204
Sensor Length (mm)	38
Switching Element	NO contact, NC contact
Switching Principle	Slow action with staggered contacts
Utilisation Category	AC-15
Utilisation Category AC-15	230 VAC
Utilisation Category DC-13	200 VDC
Contact Material	AgSn0, Ag-Ni, self-cleaning, positive drive
Degree of Protection	IP67
EAN	4030660000000
Enclosure Material	Plastic, glass-fibre reinforced thermoplastic, self-extinguishing
Maximum Ambient Temperature (°C)	80
Maximum Cable Cross Section (mm²)	2.5
Minimum Cable Cross Section (mm²)	0.25
Minimum Mechanical Life	20000000 Operations
Rated Impulse Withstand Voltage (kV)	6
Rated Insulation Voltage (V)	250
Series	BNS36
Standards	EN IEC 60947-5-1
Terminal Type	Spring pulley connection, plug-in \| rigid or flexible

Presence Sensing Safety Devices

SCHMERSAL BNS36-11/01Z-R SAFETY SENSOR 101190042
