Schmersal 101170650 Foot Switch 1NO-1NC 1000A

Product Code: 101170650

  • Rated for 1000 A current
  • Durable aluminium housing
  • IP20 protection rating
  • Complies with ENIEC standards
  • Slow action, positive break contact
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Foot Switch
Brand SCHMERSAL
Actuator Type K370 Offset Roller Lever
Cable Cross Section 1.5 sq-mm
Contact Configuration 1NO+1NC
Contact Material Silver
Degree of Protection IP20
Fuse Rating 6 A
Housing Material Aluminium
Mechanical Life 1000000 Operations
Number of Auxiliary Contacts 1
Rated Current 1000 A
Standards and Approvals ENIEC 60947-1, ENIEC 60947-5-1
Switching Type Slow Action, Positive Break NC Contact
Terminal Type M20 x 1.5 Screw

Description

<p>When you&amp;#39;re in the market for a reliable safety switch, this particular model is designed with both durability and efficiency in mind. Crafted with an aluminium housing, it provides a robust solution while maintaining a lightweight profile. This makes it suitable for various industrial and commercial applications where strength without unnecessary bulk is key.</p><p>The safety switch operates at a rated current of 1000 A. This high capacity ensures that it can handle substantial electrical loads, making it ideal for heavy-duty environments. With an IP20 degree of protection, it&amp;#39;s well-suited to indoor use where there’s minimal exposure to dust or water ingress.</p><p>Meeting international standards such as ENIEC 60947-1 and ENIEC 60947-5-1, this product guarantees compliance with essential safety and performance benchmarks. These approvals provide peace of mind that the switch adheres to rigorous quality controls.</p><p>Its contact configuration features one normally open (NO) and one normally closed (NC) contact, providing versatile switching capabilities. The inclusion of one auxiliary contact further enhances its functionality by allowing integration into more complex control systems.</p><p>A distinguishing feature is its slow action switching type combined with a positive break NC contact. This design ensures precise operation—a critical factor in safety applications where every detail counts.</p><p>The actuator type utilizes a K370 offset roller lever, known for its reliability and ease of use in varied conditions. Paired with silver contacts, which offer excellent conductivity and resistance to oxidation, you can expect consistent performance over time.</p><p>This model supports fuses up to 6 A—an important consideration when planning your circuit protection strategy. The M20 x 1.5 screw terminals facilitate secure connections while accommodating cable cross sections up to 1.5 sq-mm—adequate for many standard wiring setups.</p><p>With an impressive mechanical life rated at one million operations, you can be confident in the longevity of this product even under frequent usage scenarios—making it a cost-effective investment over time.</p><p>In summary, this safety switch combines robust construction with high operational capacity, backed by recognized standards compliance and thoughtful design features like slow action switching and durable materials—all tailored towards ensuring your installation&amp;#39;s reliability and safety needs are met efficiently.</p>

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
