Active Area |
Plastic |
|
Actuating Stroke (mm) |
4 |
|
Actuating Torque (Nm) |
0.26 |
|
Actuator Material |
Stainless steel |
|
Actuator Type to EN 50047 |
B |
|
Assured "OFF" Switching Distance (mm) |
22 | 32 |
|
Assured "ON" Switching Distance (mm) |
10 | 20 |
|
Bounce Duration |
Bounce duration in accordance with actuating speed |
|
Cable Note |
All indications including the conductor ferrules. |
|
Castor Diameter (mm) |
36 |
|
Coding Level According to EN ISO 14119 |
Low |
|
Coding Type |
Universal coding |
|
Colour of The Front Ring |
Silver |
|
Design |
Round |
|
Design of Control Element |
p-type |
|
Detection Ability for Test Bodies @ V = 1.6 m/s |
30 mm |
|
Direction of Motion |
Head-on to the active surface |
|
eCl@ss Number, Version 11.0 |
27-27-06-01 |
|
eCl@ss Number, Version 9.0 |
27-27-06-01 |
|
ETIM 6.0 |
EC001487 |
|
ETIM 7.0 |
EC000030 |
|
Explosion Protection Category |
3D | 3G |
|
Explosion Protection Zones |
22 | 2 |
|
Front Ring Material |
ABS, chrome-plated |
|
Gross Weight (g) |
300 |
|
Height of The Protection Field (mm) |
170 |
|
Housing Construction Form |
Cylinder thread |
|
Installation Conditions |
Quasi-flush |
|
Integral System Diagnostics Status |
Yes |
|
Latching Force (N) |
20 |
|
Lead Colour |
Colour code DIN47100 |
|
Lever Material |
Metal film |
|
Material of The Cable Mantle |
PVC |
|
Material of The Operators |
Aluminium |
|
Maximum Actuating Speed (m/s) |
1 |
|
Maximum Bounce Duration (ms) |
3 |
|
Maximum Electrical Power Consumption (W) |
10 |
|
Maximum Fuse Rating |
6 A gG D-fuse |
|
Maximum Holding Force (N) |
2550 |
|
Maximum Leakage Current (mA) |
0.5 |
|
Maximum No-load Supply Current (mA) |
50 |
|
Maximum Output Current (A) |
0.2 |
|
Maximum Permissible Installation Altitude Above Sea Level (m) |
2000 |
|
Maximum Protection Field (mm) |
10000 |
|
Maximum Reaction Time (ms) |
20 |
|
Maximum Relative Humidity |
95% |
|
Maximum Switching Frequency (Hz) |
5 |
|
Minimum Actuating Force (N) |
6 |
|
Minimum Actuating Speed (mm/min) |
4122 |
|
Minimum Ambient Temperature (°C) |
-25 |
|
Minimum Positive Break Force (N) |
40 |
|
Minimum Protection Field (mm) |
300 |
|
Minimum Relative Humidity |
30% |
|
Net Weight (g) |
17.321 |
|
No. of Actuating Directions |
2 |
|
No. of Auxiliary Contacts |
1 |
|
No. of Beams |
64 |
|
No. of Cable Wires |
4 |
|
No. of Safety Contacts |
1 |
|
Positive Break Torque (Nm) |
0.185 |
|
Positive Break Travel (mm) |
5 |
|
Protection Class of Operating Resource |
3 |
|
Rated Control Voltage AC/DC (V) |
24 |
|
Rated Control Voltage DC (V) |
24 |
|
Rated Operating Current (mA) |
50 |
|
Rated Short-circuit Current (A) |
1000 |
|
Recipient Terminal Connector Type |
Connector plug M12, 12-pole |
|
Recommended Actuator |
BNS-B20-B01 |
|
Recommended Safety Switchgear |
SRB-E 301 |
|
Resistance to Shock (g/ms) |
50 / 11 |
|
Roller Material |
Plastic |
|
Sealing Type |
Lip gaskets / Membrane |
|
Sensor Height (mm) |
99.5 |
|
Sensor Length (mm) |
30 |
|
Slide Form |
Castor |
|
Spacing (mm) |
50 x 50 |
|
Switching Element |
Bistable contact |
|
Switching Principle |
Slow action |
|
Switchover Time |
Switchover time in accordance with actuating speed |
|
Switchover Time (ms) |
5.5 |
|
Tolerance |
10% |
|
Unlocking |
Rotating unlatcher |
|
Utilisation Category |
DC-13 | AC-15 |
|
Utilisation Category AC-15 |
230 VAC |
|
Utilisation Category DC-13 |
24 VDC |
|
Voltage Type |
DC | AC |
|
Wavelength of The Sensor (nm) |
880 |
|
Wire Cross-Section |
13 AWG |
|
Working Principle |
Magnetic drive |
|
Brand |
SCHMERSAL |
|
Actuator Type |
Roller lever |
|
Cable Entry |
3 x M20 x 1.5 |
|
Cable Length (m) |
5 |
|
Connector Type |
Connector plug M12, 4-pole |
|
Contact Material |
Silver-nickel alloy 10 |
|
Degree of Protection |
IP67 |
|
Depth (mm) |
274 |
|
EAN |
4030660000000 |
|
Enclosure Coating Material |
Painted |
|
Enclosure Material |
Shatterproof glass |
|
Handle Colour |
Red |
|
Height (mm) |
184 |
|
Maximum Ambient Temperature (°C) |
80 |
|
Maximum Cable Cross Section (mm²) |
2.5 |
|
Maximum Switching Current (A) |
0.01 |
|
Maximum Switching Voltage AC (V) |
250 |
|
Minimum Cable Cross Section (mm²) |
0.75 |
|
Minimum Mechanical Life |
1000000 Operations |
|
Mounting Type |
Mounting flange ELM |
|
No. of Normally-open Contacts |
1 |
|
Overvoltage Category |
3 |
|
Pollution Degree |
3 |
|
Rated Impulse Withstand Voltage (kV) |
4 |
|
Rated Insulation Voltage (V) |
500 |
|
Standards |
EN IEC 60947-5-3 / BG-GS-ET-14 |
|
Storage Temperature (°C) |
-25 to 70 |
|
Terminal Type |
Screw terminals M20 x 1.5 |
|
Version |
LED - Indicator light - Front plate mounting |
|
Width (mm) |
750 |
