Active Area |
Front side |
|
Actuating Position |
Front Side / Rear / From Head |
|
Actuating Stroke (mm) |
5 |
|
Actuating Torque (Nm) |
0.31 |
|
Actuator Material |
Stainless steel |
|
Actuator Type to EN 50047 |
EB |
|
Assured "OFF" Switching Distance (mm) |
22 | 32 |
|
Assured "ON" Switching Distance (mm) |
10 | 20 |
|
Bounce Duration |
Bounce duration in accordance with actuating speed |
|
Cable Note |
All indications including the conductor ferrules. |
|
Castor Diameter (mm) |
20 |
|
Castor Width (mm) |
9 |
|
Coding Level According to EN ISO 14119 |
Low |
|
Coding Type |
Individual coding |
|
Colour of The Front Ring |
Silver |
|
Colour of The Operating Element |
Blue |
|
Design |
Round |
|
Design of Control Element |
p-type |
|
Detection Ability for Test Bodies @ V = 1.6 m/s |
35 mm |
|
Diameter of The Front Ring (mm) |
44.5 |
|
Direction of Motion |
Head-on to the active surface |
|
Door Hinge Position |
Left |
|
eCl@ss Number, Version 11.0 |
27-27-01-05 |
|
eCl@ss Number, Version 9.0 |
27-27-01-05 |
|
ETIM 6.0 |
EC000030 |
|
ETIM 7.0 |
EC001487 |
|
Explosion Protection Category |
3D |
|
Explosion Protection Zones |
22 |
|
Front Ring Material |
Aluminium |
|
Gross Weight (g) |
16.979 |
|
Height of The Protection Field (mm) |
800 |
|
Housing Construction Form |
Norm construction design |
|
Installation Conditions |
Flush |
|
Integral System Diagnostics Status |
Yes |
|
Latching Force (N) |
30 |
|
Lead Colour |
Colour code DIN47100 |
|
Lever Material |
Metal film |
|
Material of The Cable Mantle |
PVC |
|
Material of The Nuts |
Glass-fibre, reinforced thermoplastic |
|
Material of The Operators |
ABS |
|
Maximum Actuating Speed (m/s) |
18 |
|
Maximum Bounce Duration (ms) |
5 |
|
Maximum Electrical Power Consumption (W) |
10 |
|
Maximum Fuse Rating |
6 A gG D-fuse |
|
Maximum Holding Force (N) |
1300 |
|
Maximum Leakage Current (mA) |
0.5 |
|
Maximum No-load Supply Current (mA) |
100 |
|
Maximum Output Current (A) |
0.25 |
|
Maximum Permissible Installation Altitude Above Sea Level (m) |
2000 |
|
Maximum Protection Field (mm) |
10000 |
|
Maximum Reaction Time (ms) |
10 |
|
Maximum Relative Humidity |
85% |
|
Maximum Switching Frequency (Hz) |
5 |
|
Maximum Switching Voltage DC (V) |
250 |
|
Minimum Actuating Force (N) |
9 |
|
Minimum Actuating Speed (mm/min) |
10 |
|
Minimum Ambient Temperature (°C) |
-30 |
|
Minimum Positive Break Force (N) |
15 |
|
Minimum Protection Field (mm) |
300 |
|
Minimum Relative Humidity |
10% |
|
Net Weight (g) |
53 |
|
No. of Actuating Directions |
4 |
|
No. of Auxiliary Contacts |
1 |
|
No. of Beams |
56 |
|
No. of Cable Wires |
4 |
|
No. of LEDs |
1 |
|
No. of Safety Contacts |
2 |
|
Positive Break Torque (Nm) |
0.185 |
|
Positive Break Travel (mm) |
11 |
|
Protection Class of Operating Resource |
3 |
|
Rated Control Voltage AC/DC (V) |
24 |
|
Rated Control Voltage DC (V) |
24 |
|
Rated Operating Current (mA) |
400 |
|
Rated Short-circuit Current (A) |
1000 |
|
Recipient Terminal Connector Type |
Connector plug M12, 8-pole |
|
Recommended Actuator |
BPS 33-2326 | BPS 33 |
|
Recommended Safety Switchgear |
SRB-E 301 |
|
Repeat Accuracy (mm) |
0.5 |
|
Resistance to Shock (g/ms) |
30 / 11 |
|
Roller Material |
Plastic |
|
Sealing Type |
Form seals / Lip gaskets / Membrane |
|
Sensor Height (mm) |
129.5 |
|
Sensor Length (mm) |
46.5 |
|
Slide Form |
Castor |
|
Spacing (mm) |
40 x 50 |
|
Switching Element |
Opener (NC) |
|
Switching Principle |
Slow action |
|
Switchover Time |
Switchover time in accordance with actuating speed |
|
Switchover Time (ms) |
2 |
|
Thermal Test Current (A) |
0.25 |
|
Tolerance |
10% |
|
Unlocking |
Draw unlocking |
|
Utilisation Category |
DC-13 | AC-15 |
|
Utilisation Category AC-15 |
230 VAC |
|
Utilisation Category DC-13 |
24 VDC |
|
Voltage Type |
DC | AC |
|
Wavelength of The Sensor (nm) |
880 |
|
Wire Cross-Section |
23 AWG |
|
Working Principle |
Magnetic drive |
|
Brand |
SCHMERSAL |
|
Actuator Type |
Roller plunger |
|
Cable Entry |
4 x M16 x 1.5 |
|
Cable Length (m) |
3 |
|
Connector Type |
Connector plug M12, 4-pole |
|
Contact Material |
Silver |
|
Degree of Protection |
IP67 |
|
Depth (mm) |
60 |
|
EAN |
4030660000000 |
|
Enclosure Coating Material |
Powder-coated |
|
Enclosure Material |
Shatterproof glass |
|
Handle Colour |
Grey |
|
Height (mm) |
14 |
|
Housing Colour |
Black | Silver |
|
Maximum Ambient Temperature (°C) |
80 |
|
Maximum Cable Cross Section (mm²) |
1 x 1.0 , flexible |
|
Maximum Switching Current (A) |
0.4 |
|
Minimum Cable Cross Section (mm²) |
0.75 |
|
Minimum Mechanical Life |
20000000 Operations |
|
Mounting Type |
Mounting flange ELM |
|
No. of Normally-open Contacts |
1 |
|
Overvoltage Category |
3 |
|
Pollution Degree |
3 |
|
Rated Impulse Withstand Voltage (kV) |
6 |
|
Rated Insulation Voltage (V) |
250 |
|
Standards |
EN ISO 13849-1 / EN IEC 62061 / EN IEC 61496-1 / EN IEC 61496-2 |
|
Storage Temperature (°C) |
-25 to 70 |
|
Terminal Type |
Cage clamps |
|
Version |
LED - Indicator light - Front plate mounting |
|
Width (mm) |
100 |
