IDEC DC POWER SUPPLY, 2.5A, RAIL MOUNT, SLIM-LINE INPUT 85-264V AC / 100-370V DC PS5R-VC12

Product Code: PS5R-VC12

The IDEC PS5R-VC12 is a slim-line DC power supply designed for rail mounting, delivering a 12V output at 30W and 2.5A. It offers wide voltage compatibility with inputs ranging from 85-264V AC to 100-370V DC. Engineered for efficient power delivery, this unit ensures stable performance across various devices. Its compact design allows for space-saving installation, while its long-term reliability is assured with a 5-year warranty.

Technical Specifications

Efficiency 87%
Input Current (A) 100V AC: 0.7A 230V AC: 0.3A
Output Power (W) 30
Overcurrent Protection 105%
Resistance to Shock (m/s²) 300
Resistance to Vibrations 10 to 55Hz
Brand IDEC
Degree of Protection IP20
Dimensions (mm) 22.5W x 90H x 95D
Input Voltage AC (V) 100 - 240
Minimum Electrical Life 8 Years
Mounting Type DIN Rail
Operating Humidity 20 to 90%
Operational Temperature Range (°C) -25 to 70
Output Current (A) 2.5
Output Voltage DC (V) 12
Rated Frequency (Hz) 50/60
Warranty Period (Months) 60
Weight (g) 150
