RED LION CUB4 DC CURRENT METER WITH RED BACKLIGHTING CUB4I020

Product Code: CUB4I020

The DC Current Meter is a compact device measuring 39 mm x 75 mm. It features a 3 1/2 digit LCD display with a size of 0.6" (15.2 mm) and red LED backlighting for easy visibility. The meter has a wide range of measurement capabilities, from 0-199.9 uA to 199.9 mA DC. It is designed to meet the NEMA 4X/IP65 standards for protection against dust and water ingress.

Technical Specifications

Number of Display Digits 3.5
Brand RED LION
Display Screen Size (Inch) 0.6
Degree of Protection IP65
Dimensions (mm) 74.9W x 39.1H x 49.8D
Display Screen Type LCD
Inputs ±199.9 µADC, ±1.999 mADC, ±19.99 mADC, ±199.9 mADC
Operational Temperature Range (°C) 0 to 60
Rated Voltage DC (V) 9 - 28
Standards and Approvals EN 61326-1, IEC/EN 61010-1
