Electromagnetic Capability |
10 V/m (80 .. 1000 MHz)
3 V/m (1400 .. 2000 MHz)
1 V/m (2000 .. 2700 MHz) |
|
Electrostatic Discharge (kV) |
4 kV Contact Discharge, 8 kV Air Discharge |
|
Maximum Temperature (°C) |
60 |
|
Mean Time Between Failure (MTBF) |
159.3 h |
|
Minimum Temperature (°C) |
0 |
|
Network Configuration |
any |
|
Nominal Power (W) |
23 |
|
Operating Voltage Range |
2 x 24V DC (16.8 - 32 VDC) |
|
Port Quantity and Type |
6 x M12 "D"-Coded, 8 x RJ45 |
|
Rated Maximum Operational Voltage DC (V) |
32 |
|
Rated Minimum Operational Voltage DC (V) |
16.8 |
|
Relative Humidity |
5-95 % |
|
Resistance to Vibrations |
5 Hz .. 8.4 Hz (3,5 mm Amplitude), 5 Hz .. 150 Hz |
|
Software |
HiOS 09.0.06 |
|
Software Configuration |
Automatic Configuration Undo (roll-back), Configuration Fingerprint, Text-based Configuration File (XML), BOOTP/DHCP Client with Auto-Configuration, DHCP Server: per Port DHCP Server: Pools per VLAN, AutoConfiguration Adapter ACA31 (SD card), HiDiscovery, DHCP Relay with Option 82, Command Line Interface (CLI), CLI Scripting Full-featured MIB Support, Web-based Management Context-sensitive Help, Backup config on a remote server when saving, Clear config but keep IP settings, CLI script handling over ENVM at boot, HTML5 based Management |
|
Software Diagnostics |
Management Address Conflict Detection, MAC Notification, Signal Contact, Device Status Indication, TCPDump, LEDs, Syslog, Persistent Logging on ACA, Email Notification, Port Monitoring with Auto-Disable, Link Flap Detection, Overload Detection, Duplex Mismatch Detection, Link Speed and Duplex Monitoring, RMON (1,2,3,9), Port Mirroring 1:1, Port Mirroring 8:1, Port Mirroring N:1, RSPAN, SFLOW, VLAN Mirroring, System Information, Self-Tests on Cold Start, Copper Cable Test, SFP Management, Configuration Check Dialog, Switch Dump, Snapshot Configuration Feature |
|
Software Management |
DNS Client, Dual Software Image Support, TFTP, SFTP, SCP LLDP (802.1AB), LLDP-MED, SSHv2, V.24, HTTP, HTTPS, Traps, SNMP v1/v2/v3, Telnet, OPC-UA Server |
|
Software Miscellaneous |
Port Power Down, Manual Cable Crossing |
|
Software Redundancy |
HIPER-Ring (Ring Switch) HIPER-Ring over Link Aggregation Link Aggregation with LACP Link Backup Media Redundancy Protocol (MRP) (IEC62439-2) MRP over Link Aggregation Sub Ring Manager RSTP 802.1D-2004 (IEC62439-1) RSTP Guards VRRP VRRP Tracking HiVRRP (VRRP enhancements) Redundant Network Coupling |
|
Software Security |
MAC-based Port Security, Port-based Access Control with 802.1X, Guest/unauthenticated VLAN, Integrated Authentication Server (IAS), RADIUS VLAN Assignment, RADIUS Policy Assignment, Multi-Client Authentication per Port, MAC Authentication Bypass, DHCP Snooping, Dynamic ARP Inspection, Automatic Denial-of-Service Prevention, LDAP, Ingress MAC-based ACL, Ingress IPv4-based ACL, Time-based ACL, VLAN-based ACL, Ingress VLAN-based ACL, ACL Flow-based Limiting, Access to Management restricted by VLAN, Device Security Indication, Audit Trail, CLI Logging, HTTPS Certificate Management, Restricted Management Access, Appropriate Use Banner, Configurable Password Policy, Configurable Number of Login Attempts, SNMP Logging, Multiple Privilege Levels, Local User Management, Remote Authentication via RADIUS, User Account Locking, Password change on first login |
|
Software Switchng |
Independent VLAN Learning, Fast Aging, Static Unicast/Multicast Address Entries, QoS / Port Prioritization (802.1D/p), TOS/DSCP Prioritization, Interface Trust Mode, CoS Queue Management, IP Ingress DiffServ Classification and Policing, Queue-Shaping / Max. Queue Bandwidth, Flow Control (802.3X), Egress Interface Shaping, Ingress Storm Protection, Jumbo Frames, VLAN (802.1Q), Protocol-based VLAN, VLAN Unaware Mode, Voice VLAN, MAC-based VLAN, IP subnet-based VLAN, IGMP Snooping/Querier per VLAN (v1/v2/v3), Unknown Multicast Filtering, Multiple VLAN Registration Protocol (MVRP), Multiple MAC Registration Protocol (MMRP), Multiple Registration Protocol (MRP), Jumbo Frames, Layer 2 Loop Protection |
|
Software Time Synchronization |
PTPv2 Transparent Clock two-step, PTPv2 Boundary Clock, Buffered Real Time Clock, SNTP Client, SNTP ServerPTPv2 Transparent Clock two-step, PTPv2 Boundary Clock, Buffered Real Time Clock, SNTP Client, SNTP Server |
|
Transition Type |
2 kV power line, 4 kV data line |
|
Brand |
HIRSCHMANN |
|
Cable Length (m) |
0 - 100 |
|
Degree of Protection |
IP20 |
|
Dimensions (mm) |
146W x 164H x 120D |
|
Mounting Type |
DIN Rail |
|
No. of Pins |
2 |
|
Operational Temperature Range (°C) |
0 - 60 |
|
Power Consumption (W) |
23 |
|
Rated Voltage DC (V) |
2 x 24 |
|
Series |
RAIL DATA |
|
Standards |
CE, EN 60131-2 |
|
Standards and Approvals |
CE, EN60131-2, EN60950-1 |
|
Storage Temperature Range (°C) |
-40 - 85 |
|
Surge Voltage (kV) |
2 kV (Line / Ground), 1 kV (Line / Line) Power Supply 1 kV Lline/Earth) Data Line |
|
Terminal Type |
2 x Plug-In Terminal Block, 3- pin, 1 x Plug-In Terminal Block |
|
Weight (g) |
2200 |
