Current Consumption (mA) |
71 at 24VDC |
|
Electromagnetic Capability |
10 V/m (80-3000 MHz) |
|
Electrostatic Discharge (kV) |
4 kV Contact Discharge, 8 kV Air Discharge |
|
Network Configuration |
any |
|
No. of 100Mb Ports |
5 |
|
No. of Ethernet Ports |
5 |
|
Nominal Power (W) |
1.8 |
|
Operating Voltage Range |
9.6 - 32 V DC |
|
Port Quantity and Type |
5 x 10/100BASE-TX RJ45 |
|
Power Output in BTU (IT)/h |
6.1 |
|
Rated Maximum Operational Voltage DC (V) |
32 |
|
Rated Minimum Operational Voltage DC (V) |
9.6 |
|
Relative Humidity |
5-95 % |
|
Resistance to Vibrations |
3.5 mm, 5–8.4 Hz, 10 cycles, 1 octave/min
1 g, 8.4–150 Hz, 10 cycles, 1 octave/min |
|
Software Configuration |
HiDiscovery, BOOTP/DHCP, Web-based Management |
|
Software Diagnostics |
Device status indication (LEDs), Log-File, RMON (1) statistics, Simple interface statistics, Topology Discovery according to IEEE 802.1AB (LLDP) |
|
Software Management |
Web-interface, HTTP(s) config file/firmware transfer, SNMP v1/v2/v3 |
|
Software Redundancy |
RSTP (IEEE 802.1D-2004) |
|
Software Security |
SNMPv3 (authNoPriv), Possibility to disable each port |
|
Software Switchng |
TOS/DSCP prioritization (Mapping TOS/DSCP to 802.1D/p), Prioritization through 4 queues, Static unicast/multicast filter entries (up to 100), VLAN Support |
|
Transition Type |
2 kV Power Line, 4 kV Data Line |
|
Brand |
HIRSCHMANN |
|
Cable Length (m) |
0 - 100 |
|
Degree of Protection |
IP30 |
|
Dimensions (mm) |
25W x 114H x 79D |
|
Mounting Type |
DIN Rail |
|
No. of Pins |
3 |
|
Operational Temperature Range (°C) |
0 - 60 |
|
Power Consumption (W) |
1.8 |
|
Rated Operational Voltage DC (V) |
9.6 - 32 |
|
Series |
GECKO |
|
Standards and Approvals |
cUL61010-1 |
|
Storage Temperature Range (°C) |
-40 - 85 |
|
Surge Voltage (kV) |
Power Line: 2 kV (Line/Earth), 1 kV (Line/Line), 1 kV Data Line |
|
Switch Type |
Switch - Managed |
|
Terminal Type |
1 x Plug-In Terminal Block |
|
Weight (g) |
110 |
