STAHL 9270/21-14-14S SWITCHING REPEATER EX I FIELD CIRCUIT 261413

Optimize your hazardous area operations with Stahl's 9270 Series Switching Repeater, designed for Ex i field circuits. This automation interface solution features two changeover (CO) output channels and supports auxiliary power ranging from 19.2 to 30 V. It ensures efficient operation with an input current requirement of just 2.1 mA for ON and 1.2 mA for OFF states. The device is capable of handling output loads from 3 V at 5 mA to 30 V at 50 mA, with a robust output switching capacity of up to 500 VA. Engineered to withstand extreme temperatures, it operates reliably between -20°C and +60°C. Safety and durability are paramount, as evidenced by its IP30 rating, with IP20 protection at the terminals. The repeater is suitable for installation in Class I, Div. 2 environments and boasts a slim design at only 12.5 mm wide, accommodating both one- and two-channel configurations. Stahl's commitment to safety extends to functional levels; this unit can be used for applications requiring up to SIL 2 according to IEC/EN 61508 standards. Additionally, it includes a wire breakage and short-circuit monitoring system that can be disconnected while providing diagnostic messages. With screw terminal connections for secure wiring and a sleek profile that saves space on your DIN rail, the Stahl Switching Repeater is an essential component for any engineer looking to enhance system integrity in hazardous areas.
