IDEC YW1B-M1E10Y NON-ILLUMINATED PUSHBUTTON YELLOW FLUSH MOMENTARY 1NO

Product Code: YW1B-M1E10Y

The IDEC YW1B-M1E10Y is a non-illuminated, yellow flush pushbutton designed for momentary operation with a single normally open (NO) contact. It accommodates a 22mm mounting size and offers an IP20 rating for protection against solid objects. The pushbutton also includes finger-safe terminals to ensure safe wiring practices.

Technical Specifications

Brand IDEC
Bezel Type Plastic
Colour Yellow
Contact Material Silver
Contacts 1NO
Conventional Free-Air Thermal Current - Ith (A) Contact Rating - 10
Degree of Protection IP65 (Front), IP20 (Terminals)
Illumination Non-Illuminated
Insulation Resistance (MO) 100
Mode of Operation Momentary
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Series YW
Terminal Type Screw (M3.5)
